Tubes

Tubes are formed in a warmed pressure roller under high tension and temperature. A prepreg of the material is rolled onto the cast cylinders for a required period of time. After that, the cylindrical cast, usually a steel mandrel, is then pulled out and the rest material is finished as per required size.
Rolled Tubes have high mechanical strength, low water assimilation and are impervious to the compound assault of gentle acids and salts.
Tubes are available as per prevalant industry standards and are produced used finest of materials.
Available in various sizes and diameter thicknesses.

Rods

Rods are produced by curing the raw material into steel cast/mould of the desired size and thicknesses are maintained by applying pressure and temperature over the moulds.
Certain grades have self-lubricating properties which enables it in various mechanical applications.
Rods are available as per prevalant industry standards and are produced used finest of materials.
Available in various sizes and diameter thicknesses.

Components/Machined Parts

Machined Parts or components of the desired material are produced using various methods such as casting/extrusion/machining/drilling etc.
All machined parts are produced as per specific drawings provided by the customers as per their required dimensions and specifications.
Best industrial practices and norms are followed when it comes to procuring the raw material and producing fine quality components/parts.

Properties	Unit	Rods	Tubes
Grade	NEMA LI 1-1983	CE	CE
	IS 2036:2015	F4	F4
Sizes	mm	305,610,1000	1200
Thickness	mm	8.0 - 250	25 - 350
Flexural Strength	Mpa	140	150
Cohesion b/w layers	Mpa	--	150
Water Absorption	mg/cm³	3	2.9
Electrical Strength (in Oil at 90^oC)	kv	Withstandsupto 5 kv
Relative Density		1:39	1.26
Insulation Resistance (After immersionin water)	Ohms	> 10x 10⁸	> 3x10⁸
